超高亮線光(HRLNH2/HRLNHP2)
機器尺寸圖
LNH-300W-FN 照度與工作距離關系
產品規格
| 系列 | 型號 | 顏色 | 推薦工作距離(mm) | 發光口(mm) | 額定功率(w)*3 | 長度X寬度X高度(mm) | 重量 (kg) |
|---|---|---|---|---|---|---|---|
| HRLNH2/HRLNHP2 | HRLNH2/HRLNHP2-100W-FN |  | 50-100/100-200 | 100X25 | 52 | 110X46.8X99.5 | 0.5 |
| HRLNH2/HRLNHP2-200W-FN | | 50-100/100-200 | 200X25 | 105 | 210X46.8X99.5 | 0.8 | |
| HRLNH2/HRLNHP2-300W-FN | | 50-100/100-200 | 300X25 | 158 | 310X46.8X99.5 | 1.1 | |
| HRLNH2/HRLNHP2-400W-FN | | 50-100/100-200 | 400X25 | 210 | 410X46.8X99.5 | 1.4 | |
| HRLNH2/HRLNHP2-500W-FN | | 50-100/100-200 | 500X25 | 264 | 510X46.8X99.5 | 1.7 | |
| HRLNH2/HRLNHP2-600W-FN | | 50-100/100-200 | 600X25 | 316 | 610X46.8X99.5 | 2 | |
| HRLNH-A/HRLNHP-A | HRLNH/HRLNHP-700W-FN-A | | 50-100/100-200 | 700X25 | 370 | 710X50X98 | 3.3 |
| HRLNH/HRLNHP-800W-FN-A | | 50-100/100-200 | 800X25 | 410 | 810X50X98 | 3.7 | |
| HRLNH/HRLNHP-900W-FN-A | | 50-100/100-200 | 900X25 | 450 | 910X50X98 | 4.2 | |
| HRLNH/HRLNHP-1000W-FN-A | | 50-100/100-200 | 1000X25 | 490 | 1010X50X98 | 4.6 | |
| HRLNH/HRLNHP-1100W-FN-A | | 50-100/100-200 | 1100X25 | 530 | 1110X50X98 | 5.1 | |
| HRLNH/HRLNHP-1200W-FN-A | | 50-100/100-200 | 1200X25 | 570 | 1210X50X98 | 5.5 | |
| HRLNH/HRLNHP-1300W-FN-A | | 50-100/100-200 | 1300X25 | 650 | 1310X50X98 | 6 | |
| HRLNH/HRLNHP-1400W-FN-A | | 50-100/100-200 | 1400X25 | 700 | 1410X50X98 | 6.4 | |
| HRLNH/HRLNHP-1500W-FN-A | | 50-100/100-200 | 1500X25 | 750 | 1510X50X98 | 6.9 |
